Dipperlog Smart remote depth and temperature system
Remote monitoring of Water Level and Temperature
Real time readings and datalogging
Mesh network within a 10km range
Data can be collected Android tablet or provided on web app
Automatic barometric compensation
No monthly subscriptions
The Dipperlog Smart system is extremely useful tool for projects where multiple individuals or parts of a company require access to the same data. Whether this is a dewatering, construction or modelling project having instant access to data allows for successful remote monitoring
There are 4 basic elements to a complete system -
SENSOR– Measures water depth and temperature, connected via a cable
NODE– collects data from the sensor and sends wirelessly
GATEWAY– to collected the data from each node, communicates with a tablet
TABLET – communicates with the gateway, can collect data locally or upload to the cloud
Expand your system:
REPEATER – relays data from the NODES which are outside transmission range
PC Communication Cable and Software – for communication direct to the logger
SENSOR: Measures water depth and temperature
The Dipperlog data logger is attached directly to each NODE by a direct read cable, this allows for easy data transfer from the NODE to the GATEWAY. The Dipperlog can also be configured to collect and store data internally, providing data redundancy.
NODE: Water Depth & Temperature
The water depth sensor measures hydrostatic water level (depth) and temperature and is available in ranges from 10m to 120m. Each node has a built-in barometer which automatically compensates for barometric pressure influences.
GATEWAY: data coordinator
The gateway is the network Coordinator and is the location where pressure and temperature information is gathered before data is sent via Bluetooth so it can be viewed on a tablet The gateway is not internally powered, therefore needs to be connected directly to a power source. The device does feature a backup battery, which will provide power to the unit for approx. 5 days if there is a there is a power supply issue.
TABLET:
This device is offered with “Sugarheld” software installed and configured for your network. Information from the gateway is collected directly to your tablet, where information can be viewed. If you wish to access the data from the tablet in a remote location your tablet you will need a Wi-Fi or cell connection to send the data to the cloud platform. The cloud platform can also be set up to notify you of any alarm conditions being met.
REPEATER: relay for data transfer
The Repeater is a relay device for data transfer when nodes on the network are outside transmission range. This device will allow information from the nodes to be transmitted back to the gateway
Both node and repeater devices are weather proof featuring heavy duty casing and seals for outdoor deployment. When used together these devices create the “spidermesh”, stand-alone data transfer network whose size is defined only by the number of units deployed with an unlimited capacity.
Choosing a Dipperlog for your Dipperlog Smart system –
Dipperlog 64 – highly accurate water level and temperature data logger, featuring a 64,000 data points memory,
stainless steel body and transducer
Dipperlog Tough– highly accurate water level and temperature data logger with 64,000 data points,
titanium body and transducer
