Ultrasonic Level Transmitters
Non-Contact Ultrasonic Level Measurement Senors for liquids and solids
Measurement Principle: The Sensor head emits an ultrasonic pulsed signal towards the liquid or solid being measured, which then bounces back like an echo from the surface of the media. The sensor head then calculates the time elapsed between pulse emission and reception using filtering algorithms to generate a measurement which is proportionate to the level measurement in the tank or silo. This happens many times every second to provide continuous and accurate level measurements.
Δ Various Material and Connection choices to suit your application
Δ Automatic temperature compensation for accurate measurement
Δ Complex signal processing technology optimses measurement data
Δ ATEX Hazardous Area Approval optional
Δ Local Display and 4-20mA output (Hart Protocol enabled)
Δ Programming via LCD or PC Software Package
-
Ultrasonic Level Sensor 0-3 Metre Range, 4-20mA - 12V DC
SKU: BFL740-3
Ultrasonic Level Sensor 0-3 Metre Range
4-20mA (2 wire) - 12V DC Power
Accuracy +/- 0.5% F.S
300mm Deadband
Beam Angle 15º
IP67 Rating£200.00
£240.00 inc VAT -
Ultrasonic Level Sensor 0-5 Metre Range, 4-20mA - 12V DC
SKU: BFL740-5
Ultrasonic Level Sensor 0-5 Metre Range
4-20mA (2 wire) - 12V DC Power
Accuracy +/- 0.5% F.S
300mm Deadband
Beam Angle 15º
IP67 Rating£200.00
£240.00 inc VAT -
Ultrasonic Level Sensor 0-7 Metre Range, 4-20mA - 12V DC
SKU: BFL740-7
Ultrasonic Level Sensor 0-7 Metre Range
4-20mA (2 wire) - 12V DC Power
Accuracy +/- 0.5% F.S
350mm Deadband
Beam Angle 12º
IP67 Rating£246.00
£295.20 inc VAT -
Ultrasonic Level Sensor 0-10 Metre Range, 4-20mA - 12V DC
SKU: BFL740-10-LP
Ultrasonic Level Sensor 0-10 Metre Range
4-20mA (2 wire) - 12V DC Power
Accuracy +/- 0.5% F.S
500mm Deadband
Beam Angle 12º
IP67 Rating£330.00
£396.00 inc VAT -
Ultrasonic Level Sensor 0-10 Metre Range, 4-20mA - 12V DC
SKU: BFL740-10-HP
Ultrasonic Level Sensor 0-10 Metre Range
4-20mA (2 wire) - 12V DC Power
Accuracy +/- 0.5% F.S
500mm Deadband
Beam Angle 9º
IP67 Rating£330.00
£396.00 inc VAT -
Ultrasonic Level Sensor 0-12 Metre Range, 4-20mA - 12V DC
SKU: BFL740-12
Ultrasonic Level Sensor 0-12 Metre Range
4-20mA (2 wire) - 12V DC Power
Accuracy +/- 0.5% F.S
600mm Deadband
Beam Angle 9º
IP67 Rating£350.00
£420.00 inc VAT -
Ultrasonic Level Sensor 0-15 Metre Range, 4-20mA - 12V DC
SKU: BFL740-15
Ultrasonic Level Sensor 0-15 Metre Range
4-20mA (2 wire) - 12V DC Power
Accuracy +/- 0.5% F.S
600mm Deadband
Beam Angle 9º
IP67 Rating£370.00
£444.00 inc VAT -
Ultrasonic Level Sensor 0-3 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-3
Ultrasonic Level Sensor 0-3 Metre Range
4-20mA (2 wire) 12- 30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£330.00
£396.00 inc VAT -
Ultrasonic Level Sensor 0-5 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-5
Ultrasonic Level Sensor 0-5 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£350.00
£420.00 inc VAT -
Ultrasonic Level Sensor 0-8 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-8
Ultrasonic Level Sensor 0-8 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£360.00
£432.00 inc VAT -
Ultrasonic Level Sensor 0-10 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-10
Ultrasonic Level Sensor 0-10 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£378.00
£453.60 inc VAT -
Ultrasonic Level Sensor 0-12 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-12
Ultrasonic Level Sensor 0-12 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£436.00
£523.20 inc VAT -
Ultrasonic Level Sensor 0-15 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-15
Ultrasonic Level Sensor 0-15 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£492.00
£590.40 inc VAT -
Ultrasonic Level Sensor 0-20 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-20
Ultrasonic Level Sensor 0-20 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£608.00
£729.60 inc VAT -
Ultrasonic Level Sensor 0-25 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-25
Ultrasonic Level Sensor 0-25 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£956.00
£1147.20 inc VAT -
Ultrasonic Level Sensor 0-30 Metre Range, 4-20mA - 12-30V DC
SKU: BFL741-30
Ultrasonic Level Sensor 0-30 Metre Range
4-20mA (2 wire) - 12-30V DC Power
Accuracy +/- 0.25% F.S
Beam Angle <12º
IP67 Rating£990.00
£1188.00 inc VAT
