Vaisala WXT533 Compact Weather Station
Zoom
Created with Sketch.
Vaisala WXT533 Compact Weather Station
SKU: WXT530-3
Compact Weather Station
Measures
Rainfall, Windspeed and Direction
Digital Communication Options
Low power consumption
Suitable for use with data logger or telemetry system
Communication Interface
SDI-12 v 1.3, 1200 baud, 7,E,1 (+£0.00)
RS-232, Standard ASCII auto, 19200 baud,8,N,1 (+£0.00)
RS-485, Standard ASCII polled, 19200 baud,8,N,1 (+£0.00)
RS-485, Standard ASCII polled, 9600 baud,8,N,1 (+£0.00)
RS-422, Standard ASCII auto, 19200 baud,8,N,1 (+£0.00)
RS-422 NMEA 0183 v3.0, 4800 baud,8,N,1 (+£0.00)
USB/RS-232, 1.4m USB/M12 cable, ASCII auto, 19200 baud,8,N,1 (+£100.29)
USB/RS-485, 1.4m USB/M12 cable, ASCII polled, 19200 baud,8,N,1 (+£100.29)
Data Connector
No connector (bushing and grounding accessories included) (+£0.00)
8-pin M12 male connector (bushing & grounding accessories included) (+£56.57)
Heating
None (+£0.00)
Heating (+£101.57)
Cable
No Cable (+£0.00)
Shielded 2 meters long cable with 8-pin M12 connector on one end (+£93.86)
Shielded 10 meters long cable with 8-pin M12 connector on one en (+£164.57)
Shielded 20 meters long cable with 8-pin M12 connector on both ends (+£192.86)
Shielded 40 meters long cable, 12 wires, open ends on both cable ends (+£349.71)
Installation Accessories
None (+£0.00)
Mouning Kit (+£99.00)
Bird Spike (+£118.29)
Mounting Kit and Bird Spike (+£192.86)
Supporting Software
None (+£0.00)
Configuration Tool for Windows + USB service cable (+£140.14)
£3067.79
£3681.35 inc VAT
Qty:
Add to quote
Add to cart
Description
SKU
WXT530-3
Vaisala WXT533
Compact Weather Station
Measures Rainfall, Windspeed and Direction
Digital Communication Options
Low power consumption
Suitable for use with data logger or telemetry system
The WXT533 is an compact weather station offering the measurement of Rainfall, Windspeed and Direction. This unit design means the rain gauge is able to record rain fall events without the risk of flooding, clogging, wetting or evaporation loss. While the wind speed and direction sensors triangular unit design means the sensor offers excellent data availability, with a maintenance free design. The compact designs means it can easily be used for portable or permanent application. The weather station is available with a wide range of outputs including - SDI-12, RS-232, RS-485, or RS-422. The Outputs available allow the sensor to be integrated into a local data logger or telemetry system such as our
Metasphere Telemetry Systems
Specification
Related Products
Mace HydroMace XCI
SKU: 850-367
Datalogging Telemetry platform
Can be configured with up to 5 input cards
Options for SDI-12, Analog and Digital inputs
Can be used with flow, water quality and weather sensors
Mains, battery and solar powered options
Access your data remotely with WebComm Free Internet Cloud Portal
£1460.00
Product Details
Downloads
WXT530-Datasheet.pdf
(257.1 kB)
